J.W. Speaker 8910 Evolution 2 LED Heated Headlights

J.W. Speaker 8910 Evolution 2 LED Heated Headlights

Brand: J.W. Speaker
Origin: USA


J.W. Speaker 8910 Evolution 2 LED Heated Headlights

Click for:

J. W. Speaker has raised the bar for 5″ x 7″ LED headlights. Both new models comply with NHTSA’s proposed guidelines for a 5-Star safety rating, delivering more light output and less glare. The 8910 Evolution 2 also provides a Dual Burn™ high beam, for powerful punch of light.

Designed for plug & play installation and compatible with DRL systems, the Model 8900 Evolution 2 is the ideal headlight for commercial vehicles where visibility is critical to ensuring productivity.

The 8910 Evolution 2 Heated Headlights features SmartHeat™ technology, with a heated lens to de-ice during extreme cold and ensure safe operation all year long. Whether used for delivery, mining, logging, waste disposal or over-the-road driving, these headlights deliver superior visibility, extreme durability and unparalleled longevity.



J.W. Speaker 8910 Evolution 2 LED Heated Headlights Features & Benefits

  • SmartHeat™ technology to automatically de-ice lenses according to temperature
  • Dual Burn™ High Beam with high/low beam optics on at same time for an extra punch of light
  • Hard-coated PC lens to prevent cracking and formulated to resist UV or chemical damage
  • Sealed to IP69K for protection from high pressure wash & steam cleaning
  • Plug & play for standard 5″ x 7″ headlights and compatible with DRL systems



J.W. Speaker 8910 Evolution 2 LED Heated Headlights Specifications

Light sourceLEDs
eLumens1,320 Lu (high beam); 975 Lu (low beam)
rLumens3,015 Lu (high beam); 2,250 Lu (low beam)
Beam PatternForward Lighting - High Beam (DOT/ECE)
Forward Lighting - Low Beam (DOT/ECE)
Signalization - Front Position
Current Draw5.35A @ 12V DC (High Beam)
4.30A @ 12V DC (Low Beam)
2.80A @ 12V DC (Front Position)
2.10A @ 24V DC (High Beam)
2.50A @ 24V DC (Low Beam)
1.32A @ 24V DC (Front Position)
Voltage12-24V DC
Operating Temperature-40°C to +65°C (-40°F to +149°F)
Transient Spike Protection150V Peak @ 1 HZ-100 Pulses
IP RatingIP69K
ComplianceFMVSS 108 Table XIX, FMVSS 108 Table XVIII, ECE Reg. 112, ECE Reg. 7, Buy America Standards
Shape / FittingRetrofits 2B1 5" X 7" Headlights
HousingDie-Cast Aluminum
Bezel Colour OptionsChrome, Black
LensClear polycarbonate
ConnectorH4 AMP#172615-2
WiringH4
Weight2.80 lbs / 1.27 kgs
Dimensions (DxWxH)3.73x7.87x5.6” (95x200x142mm)
APS PN JWS PN
SPE-0554421 0554421
SPE-0554441 0554441
SPE-0554461 0554461
SPE-0554481 0554481



J.W. Speaker 8910 Evolution 2 LED Heated Headlights Specification Flyer (PDF)


Applications: 5" x 7" aftermarket headlights for trucks, utility and service vehicles in extreme snow and ice conditions
