J.W. Speaker Model 892 Compact Work Light 1603961

J.W. Speaker Model 892 Compact Work Light 1603961

Brand: J.W. Speaker
Origin: USA


J.W. Speaker Model 892 Compact Work Light

Click for:

Move forward with confidence with the Model 892 LED Compact Work Light 1603961. This powerful LED work light projects a wide beam of light via custom lens optics producing 3,800 lumens in front of your vehicle for incredible visibility. Use it in agriculture, construction, mining and even off-road environments to stay active, productive and safer at all hours and in any weather.

Built with sturdy aluminum housing and an impact-resistant polycarbonate lens, the Model 892 shines brightest for crews in the harshest, most demanding worksites. The durable, pedestal-mounted and corrosion-resistant LED light fits easily on a wide range of work vehicles for nonstop productivity. Designed with thermal throttling protection for construction and agriculture applications, the Model 892 performs above the rest. Rated IP67 and IP69K, the Model 892 withstands bumps, thumps and vibrations common when used in tough, weather-adverse sites.

J.W. Speaker Model 892 Compact Work Light Features & Benefits

  • Rugged polycarbonate impact-resistant lens
  • Sturdy black aluminum, corrosion-resistant housing
  • Internal components fully encapsulated for moisture-, vibration- and corrosion-protection

J.W. Speaker Model 892 Compact Work Light Specifications

Input Voltage12-24V DC
Operating Voltage9-30V DC
rLumens6372 lumens
eLumens3800 lumens
Candela Output5839
Nominal LED Color Temperature5050K
Transient Spike Protection330V Peak @ 1 HZ-100 Pulses
Current Draw4.38A @ 12V DC (Power)
1.84A @ 24V DC (Power)
Outer Lens MaterialPolycarbonate
Outer Lens ColorClear
Housing MaterialAluminum
Mounting TypePedestal
Minimum Operating Temperature-40 °C / -40 °F
Maximum Operating Temperature60 °C / 140 °F
Mating ConnectorDeutsch DT06-2S-E003
Weight1.03 lbs / 0.47 kgs
Standards ComplianceBuy America Standards, Eco Friendly, IEC IP69K, ECE Reg 10, IEC IP67, Tested to ECE Reg. 10 (Radiated Emissions Only)
APS PN JWS PN
A892 1603961



J.W. Speaker Model 892 Compact Work Light Specification Flyer (PDF)


Applications: Mining, construction, material handling, utility vehicles, specialty vehicles, agriculture, automotive and off-road 4x4
