Brand:
J.W. Speaker
Origin: USA
Click for:
The J.W. Speaker Model 526 – 6″ x 6″ LED Work Lights is available in our traditional flood, trapezoid, and spot beam patterns, as well as an innovative new Anti-Glare beam pattern. Whereas conventional mining haul truck lights create unsafe glare which can blind oncoming vehicles, and angling them down impairs their effectiveness, the Model 526 Anti-Glare beam pattern has been engineered to maximize visibility without blinding oncoming vehicles.
J.W. Speaker 526 – 6″ x 6″ LED Work Lights Features & Benefits ▲
- Die-cast aluminum housing that is sealed to IP69K
- Your choice of durable glass or polycarbonate lens
- Available in multiple beam patterns, including the innovative new Anti-Glare beam pattern
- 24 Volt Versions are available for Theft Deterrence
J.W. Speaker 526 – 6″ x 6″ LED Work Lights Specifications ▲
| Type | LED Work Light |
| eLumens | 5,800 Lu |
| rLumens | 9,000 Lu |
| Beam Pattern | Flood, Spot, Trapezoid, Anti-Glare or Dual White Anti-Glare Beam Pattern |
| Current Draw | 9A @ 12V DC 5A @ 24V DC |
| Voltage | 12-24V DC or 24V DC only |
| Operating Temperature | -40°C to +65°C |
| Housing | Black die-cast aluminium |
| Lens | Polycarbonate or Glass Lens |
| Lens Colour | Clear |
| Electrical Connection | iCONN Connector - iMATE23 |
| IP Rating | IP69K |
| Mounting | Pedestal with (x1) M10-1.5 x 25 mounting bolt |
| Weight | 4.50 (lbs) / 2.04 (kgs) |
| Warranty | 5 Years |
| APS PN | JWS PN |
| 526*-24V-BLK | 1300581, 1300591, 1300601 |
J.W. Speaker 526 – 6″ x 6″ LED Work Lights Specification Flyer (PDF) ▲
NEW Dual White Anti-Glare Beam Pattern
The new LED work light with yellow housing, polycarbonate lens & dual white anti-glare beam pattern features a wiring setup that toggles the light colour temperature output for: Warm White (2800K) or Cool White (5000K).
Dual White Anti-Glare Beam Pattern – Photometric Specifications
JW_526 Yellow Dual-white Anti-glare Photometric” width=”724″ height=”384″ />
Applications: Construction, industrial, material handling, mining, railroad, specialty vehicles, agriculture, automotive and off-road 4x4
Dimensions:
Width: 6.2" (157.48 mm), Height: 6.3" (160.02 mm), Depth: 3.8" (96.52 mm)
J.W. Speaker 526 – 6″ x 6″ LED Work Lights Parts Enquiry ▲
12-24V LED Work Light with Black Housing, Polycarbonate Lens & Flood Beam Pattern, 1300431
12-24V LED Work Light with Black Housing, Polycarbonate Lens & Anti-Glare Beam Pattern, 1300461
12-24V LED Work Light with Black Housing, Polycarbonate Lens & Spot Beam Pattern, 1300441
12-24V LED Work Light with Black Housing, Polycarbonate Lens & Trapezoid Beam Pattern, 1300451
12-24V LED Work Light with Black Housing, Polycarbonate Lens & Trapezoid Beam Pattern – 2 Light Kit, 1300483
24V LED Work Light with Black Housing, Polycarbonate Lens & Flood Beam Pattern, 1300581
24V LED Work Light with Black Housing, Polycarbonate Lens & Trapezoid Beam Pattern, 1300591
24V LED Work Light with Black Housing, Polycarbonate Lens & Anti-Glare Beam Pattern, 1300601
12-24V LED Work Light with Yellow Housing, Polycarbonate Lens & Flood Beam Pattern, 1300201
12-24V LED Work Light with Yellow Housing, Polycarbonate Lens & Anti-Glare Beam Pattern, 1300191
12-24V LED Work Light with Yellow Housing, Polycarbonate Lens & Spot Beam Pattern, 1300221
12-24V LED Work Light with Yellow Housing, Polycarbonate Lens & Trapezoid Beam Pattern, 1300211
12-24V LED Work Light with Yellow Housing, Glass Lens & Flood Beam Pattern, 1300061
12-24V LED Work Light with Yellow Housing, Glass Lens & Anti-Glare Beam Pattern, 1300051
12-24V LED Work Light with Yellow Housing, Glass Lens & Spot Beam Pattern, 1300081
12-24V LED Work Light with Yellow Housing, Glass Lens & Trapezoid Beam Pattern, 1300071
24V LED Work Light with Yellow Housing, Polycarbonate Lens & Dual White Anti-Glare Beam Pattern, 1300571
