Brand:
J.W. Speaker
Origin: USA
Click for:
When you’re looking for the most illumination possible, look no further than the Model 623. Boasting bright, white light, the Model 623 high-output LED scene light is J.W. Speaker’s most powerful product yet. It is perfect for a wide range of uses, including mining equipment, light towers, and any application for which you need a vast amount of light.
J.W. Speaker 623 15″ x 8″ Rectangular LED Work Light Features & Benefits ▲
- 20,000 eLumens and 40,000 rLumens
- Available in 24-48V DC or 100-277V AC configurations
- Wide Flood, Medium Flood & Narrow Flood beam patterns available
- Durable glass lens stands up to harsh environmental conditions
- Rugged solid state LEDs can withstand shock & vibration
- Long-lasting LEDs mean never having to replace another bulb again!
- Die-cast aluminium housing provides maximum protection
- Universal mount
J.W. Speaker 623 15″ x 8″ Rectangular LED Work Light Specifications ▲
24V DC Version
| Voltage | 24V DC |
| Current Draw | 10A @ 24V DC |
| eLumens | 20,000 Lu |
| rLumens | 40,000 Lu |
| IP Rating | IP67 |
| Lens Pattern | Wide Flood, Medium Flood or Narrow Flood |
| Lens Material | Glass |
| Housing Material | Die-Cast Aluminum |
| Mounting | Universal Mount |
| Warranty | 4 Year Limited Warranty |
J.W. Speaker 623 15″ x 8″ Rectangular LED Work Light Specifications ▲
80-270V AC Version
| Voltage | 100-277V AC |
| Current Draw | 4.0A @ 115V AC |
| eLumens | 20,500 Lu |
| rLumens | 33,600 Lu |
| IP Rating | IP67 |
| Lens Pattern | Wide Flood, Medium Flood or Narrow Flood |
| Lens Material | Glass |
| Housing Material | Die-Cast Aluminum |
| Mounting | Universal Mount |
| Warranty | 4 Year Limited Warranty |
J.W. Speaker 623 15″ x 8″ Rectangular LED Work Light Parts Enquiry ▲
Part#
Description
A623WF-24V
A623 Wide Flood 24V LED Work Light
A623MF-24V
A623 Medium Flood 24V LED Work Light
A623NF-24V
A623 Narrow Flood 24V LED Work Light
A623MF-80-270V
A623 Medium Flood 80-270V LED Work Light
A623WF-80-270V
A623 Wide Flood 80-270V LED Work Light
A623NF-80-270V
A623 Narrow Flood 80-270V LED Work Light
