Brand:
ABL Lights
Origin: USA
Click for:
The New ABL 3800 Combination Drive light is SAE/ECE approved for on-road and off-road vehicles. The clear glass lens and free-form reflector provide ideal road illumination in an innovative but rugged and durable design. Along with numerous mounting operations, this light incorporates a moisture-eliminating breather, parking light, and an optional side repeater. These options allow this light to be customized for use on any vehicle globally
ABL 3800 Combination Driving Light Specifications ▲
| Bulb | H4, PY21, W5W |
| Light Pattern | ECE R112 High / Low Beam, ECE R6 Turn Signal and Repeater, ECE R7 Pilot Light, SAE FMVSS108, ANSI/ASAE S279.14 |
| Voltage | 12V, 24V |
| Intensity | 2.92A @ 24V (Low Beam) |
| Water Tightness | IP66, IP69K |
| Operating Temperature | -40°C to +85°C |
| Salt Spray | ISO 9227 |
| Housing | Black Fibre Reinforced Plastic |
| Lens | Hardened Lens |
| Mounting Options | -P (Pedestal), -S (Suspended), -R (Rear), -VR (Vertical Right), -VL (Vertical Left), -VRE (Vertical Rear) |
| Connection | Integrated 6-pin DT |
| Approval | ECE, SAE |
| Reflector | Aluminized thermal grade plastic |
ABL 3800 Combination Driving Light Specifications Flyer (PDF) ▲
Applications: Construction, Agriculture, Off-Road Equipment
Dimensions:
Width: 9.4" (240 mm), Height: 8.3" (211 mm), Depth: 5" (127 mm)
ABL 3800 Combination Driving Light Parts Enquiry ▲
Model 3800 Comb. Headlight/Turn Signal 12v 60/55W – Pedestal Mount
Model 3800 Comb. Headlight/Turn Signal 12V 60/55W – Rear Mount
Model 3800 Comb. Headlight/Turn Signal 12V 60/55W – Suspended Mount
Model 3800 Comb. Headlight/Turn Signal 12V 60/55W – Vertical Left Mount
Model 3800 Comb. Headlight/Turn Signal 12V 60/55W – Vertical Right Mount
Model 3800 Comb. Headlight/Turn Signal 12V 60/55W – Vertical Rear Mount
Model 3800 Comb. Headlight/Turn Signal 24V 75/70W – Pedestal Mount
Model 3800 Comb. Headlight/Turn Signal 24V 75/70W – Rear Mount
Model 3800 Comb. Headlight/Turn Signal 24V 75/70W – Suspended Mount
Model 3800 Comb. Headlight/Turn Signal 24V 75/70W – Vertical Left Mount
Model 3800 Comb. Headlight/Turn Signal 24V 75/70W – Vertical Right Mount
Model 3800 Comb. Headlight/Turn Signal 24V 75/70W – Vertical Rear Mount
