Brand:
PreView
Origin: USA
Click for:
The PreView WorkZone is a solid-state, pulsed radar object detection system designed to alert vehicle operators to the presence of obstacles. The sensor detects both moving and stationary objects in a pre-defined coverage area and can report the distance of the closest object via visual range indicators (display) and an audible signal (display or buzzer) to the vehicle operator.
Engineered for light to medium-sized work vehicles, the WorkZone is ideal for vehicles that require close-in, corner-to-corner blind-spot protection, from a busy worksite to a narrow neighbourhood street or alley. The antenna assembly transmits and receives low power 5.8GHz radar signals, which can process and report detections within half a second allowing the vehicle operator to quickly respond to any object within the detection zone.
PreView® WorkZone Features & Benefits ▲
- 5.8 GHz pulsed radio frequency for worldwide use
- Encapsulated to protect from dust and moisture to IP67
- 0.2A maximum current draw
- Utilizes standard CAN communication
- Available in 3m (10’) or 4.5m (15’) narrow pattern
- Available in audible warning only or audible/visual warning configuration
PreView® WorkZone Specifications ▲
| Detection Ranges | WZPV5210: 3m (10’) WZPV5215: 4.5m (15’) |
| Electronics | Solid state |
| Connector | Conxall 72x1-8PG series |
| Transmitter Frequency | 5.8GHz Pulsed RF operating under FCC Part 15.249 |
| Voltage | 9-33VDC, over voltage protected to 150V |
| Current Draw | 0.2 amp maximum, inrush current limited to 1A |
| Vibration | 25Grms (all three axis) |
| Shock | 25G (all three axes) |
| IP Rating | IP67K |
| Compliance | Compliant with FCC Part 15.249 (5725-5875MHz) FCC ID: OXZWZPV2009 ‘CE’ ‘E” Mark E11 10R-045212 |
| Operating Temperature | -40°C to +85°C |
| Data Update Rate | 70 ms |
| Target Detection Time | 300ms |
| J1939 CAN Bus | CAN 2.0B, 250 KB/s |
| Power Connection | Two 20 AWG wires, connect to reverse signal lamp circuit |
| Polarity | Negative ground, Polarity protected to 150V |
| Housing (sensor) | Polycarbonate radome |
| Sensor Mount | Four 0.22" (5.6mm) diameter mounting holes |
| Sensor Weight | 1.92 lb (0.87 kg) |
| Sensor Dimensions (DxWxH) | 1.75x9.24x4.38" (44x235x111mm) |
PreView® WorkZone Specifications Flyer (PDF) ▲
Manuals
Installation Guide
- PreView WorkZone Installation Guide
- PreView WorkZone with SAS Installation Guide
- PreView WorkZone with VideoLink Installation Guide
Applications: Light to medium-sized work trucks, construction, utilities, service trucks
Dimensions:
Width: 9.24" (235 mm), Height: 4.38" (111 mm), Depth: 1.75" (44 mm)
