Vision X Dark Sky 50W Junction Box Light

Vision X Dark Sky 50W Junction Box Light

Brand: Vision X
Origin: USA

Click for:

•   Features & Benefits
•   Photos & Images
•   Specs Table
•   Specs Flyer (PDF)
•   Parts Enquiry
•   Related Products

The 50-Watt fixture is designed with a painted bezel to eliminate light bleed. Unlike tradition fixtures, LEDs consume less power while emitting effective lumens, are more flexible with light content, and do not require a warm-up period resulting in wasted energy. Vision X LED fixtures are enhanced with Pulse Width Modulation (PWM) technology achieving a 50,000+ hour lifespan.

Vision X Dark Sky 50W Junction Box Light Features & Benefits  ▲

  • Color Temperature: 2800K
  • Wattage: 50W
  • Operating Voltage: 90-305VAC
  • IP-68, IP69K
  • Beam Patterns Available: 10, 25, 40, 60, 90, 3065 (Elliptical)

Vision X Dark Sky 50W Junction Box Light Specifications  ▲

Type25 x MHB-B (CREE) LEDs
Beam PatternsSpot 10°, Narrow 25°, Medium 40°, Flood 60°, Wide Flood 90° or Elliptical
Colour Temperature 2800K
Mounting OptionsStandard Mount Feet, Wall Mount or Dual Bracket
Voltage90-305V AC
Wattage50W
Operating Temperature-40°C to +60°C
Vibration15.6Grms
IP RatingIP68, IP69K
Certifications / RatingsEMC Emission: EN55022,EN61000-3-2, Class A ,EN61000-3-3. EMC Immunity: EN55024, EN61000-4-2,3,4,5,6,8,11; light industry level (surge 2KV), criteria A
Short CircuitConstant current limiting, recovers automatically after fault condition is removed
LensPolycarbonate Lens
Weight8 lbs (3.8kg)
Dimensions (D, W, H)3.33x12.99x7.09” (84.5x330x180mm)

Vision X Dark Sky 50W Junction Box Light Specifications Flyer (PDF)  ▲

Applications: Structural

Dimensions:
Width: 12.99" (330 mm), Height: 7.09" (180 mm), Depth: 3.33" (84.5 mm)
